Crossheads
FIXED CENTER CROSSHEADS
| CROSS HEADS | Max Tip/Conductor Size | Max Die/Wire Size | Single Layer | Skin | Strip | Triple Layer |
|---|---|---|---|---|---|---|
| 4/6 | 4mm/O.160 | 6mm/O.250 | YES | YES | YES | YES |
| 8/14 | 8mm/O.325 | 14mm/O.555 | YES | YES | YES | |
| 15/18 | 15mm/O.590 | 18mm/O.700 | YES | YES | YES | |
| 16/20 | 16mm/O.650 | 20mm/O.800 | YES | YES | YES | YES |
| 25/35 | 25mm/1.OOO | 35mm/1.375 | YES | YES | YES | |
| 35/45 | 35mm/1.375 | 45mm/1.1775 | YES | YES | YES | |
| 50/70 | 50MM/2.363 | 70mm/3.125 | YES | YES | YES |
Manual Center Crossheads
| Cross Heads | Max Tip/Conductor Size | Max Die/Wire Size | Skin | Strip |
|---|---|---|---|---|
| 6/10 | 6mm/O.250 | IOmm/O.400 | YES | YES |
| 10/20 | 10mm/O.400 | 20mm/O.800 | YES | YES |
| 20/30 | 20mm/O.800 | 30mm/1.125 | YES | YES |
| 35/45 | 35mm/1.125 | 45mm/1.500 | YES | YES |
| 40/60 | 40mm/1.500 | 60mm/2.500 | YES | YES |
| 60/80 | 60mm/2.500 | 80mm/3.125 | YES | YES |
| 80/100 | 80mm/3.125 | IOOmm/3.400 | YES | YES |
| 100/120 | IOOmm/3.400 | 120mm/4.725 | YES | YES |
| 120/140 | 120mm/4.725 | 140mm/5.500 | YES | YES |
